FWT32-59ML-50HT Matrix optical sensor

Model:FWT32-44ML-35HT

Imported fiber core, strong light transmission, good light conductivity; Region detection, the light is uniform; Fiber bending resistance, bending radius R25; Strong adaptability, can be adapted to various brands of amplifiers. ModelFWT32-59ML-50HTDetectionThrough BeamExit Surface50mmFiber Optic Cor......

Imported fiber core, strong light transmission, good light conductivity;

Region detection, the light is uniform;

Fiber bending resistance, bending radius R25;

Strong adaptability, can be adapted to various brands of amplifiers.



Model
FWT32-59ML-50HT
Detection
Through Beam
Exit Surface
50mm
Fiber Optic Core
32-core
Bending Radius
R25
Detection Distance
0-500mm
Product Size
44x19x6mm
Fiber Diameter
φ2.6
Fiber Inner Diameter
φ0.25*32
Operation Temperature
-40~55℃
Shell Material
Aluminium
Metallic Sheath
NO
Line Length
Standard configuration of 1m,customizable wire length
Adapted Amplifier Model
General
