Product Characteristics:
Measuring range: 150-1000mm
Output mode: with switching and RS485 communication (support ModBus protocol)
Linearity accuracy: ± 0.3% F.S. (150-450mm); ± 0.6% F.S. (450-1000mm)
Resolution: 50um at 150mm; 2mm at 1000mm
Spot size: Φ3mm at 1000mm
Response time: 2ms/16ms/40ms settable
Ambient light resistance: incandescent light ≥ 3,000lux
Operation panel: OLED digital display
Temperature drift: ±0.02%F.S./°C
Parameters：
High Precision Type
Linear Accuracy
Linear Precision
Standard Type
RS485+1CH
FLR-10-RS485
FLR-50-RS485
FLR-100-RS485
4-20mA+1CH
FLR-10-AA
FLR-50-AA
FLR-100-AA
RS485+1CH
FLR-10-RS485-M
FLR-50-RS485-M
FLR-100-RS485-M
4-20mA+1CH
FLR-10-AA-M
FLR-50-AA-M
FLR-100-AA-M
Spot Size
1*3mm@100mm
ф2.5mm@500mm
ф3mm@1000mm
Measuring Range
30-100mm
80-500mm
150-1000mm
F.S
70mm
420mm
850mm
Standard Type:
RS485:+0.3%FS.4-20mA:+0.4%FS
RS485:+0.3%FS.4-20mA:±0.4%FS
士0.6%FS
High Precision Type:
0.1%F.S.
80-250mm:+0.15%FS250-500mm:士0.3%FS
150-450mm:士0.3%FS450-1000mm:±0.6%FS
Repeatability
10um@30mm
30um@80mm
100um@150mm
30um@50mm
250um@250mm
520um@500mm
100um@100mm
1000um@500mm
4000um@1000mm
Resolution Ratio
5um@30mm
15um@80mm
50um@150mm
50um@100mm
500um@500mm
2000um@1000mm
Light Source
Red laser (650nm); Laser level: Class ll
Supply Voltage
RS485:10~30VDC/4-20mA:12~24VDC
Pressure Drop
<2.5V
Power Consumption
<700mW
LOAD
<200mA
Protection Circuit
polarity protection,surge protection, overload protection
